Zhongliqi sublimation offset ink

Zhongliqi sublimation offset ink

Product Introduction

Our sublimation offset printing ink is used on all kinds of offset machine(one color, two color and four color machines) .
Be adaptable to the demand for medium-speed or high-speed printing.

Suitable Fabrics

Polyester fabric,

Triacetate fabric,

Nylon fabric,

Acrylic fabric,

Polypropylene nitrile

Transfer Paper

Coated paper,

offset paper,

chrome paper,

calendered paper.

Transfer paper should be 80-90 gr/m² with dimensional stability.

Transfer temparature

About 185~220°C

Transfer time

About 20~40 seconds

Use Method

1.Print the image on paper, and normal paper is ok.

2. Put the printed paper on substrate, such as polyester and nylon fabric.

3. Put the paper and fabric on the heat-transfer machine. When the temperature reaches 180-220°C, the image will be transfer printed from paper onto the substrate.

1.Dye degree:(European Standard)

Color fastness
Color	Magenta(HPA604)	Yellow(HPA204)	Blue(HPA404)	Black(HPA804)
Rank	5-6	6	4	4

2.Transfer Temperature

Fabric Name	Transfer Temperature	Transfer Pressure	Transfer Time
Polyester Fabric	205°C~220°C	0.5kg/cm2	10~30s
Polyester low flexibility Fabric	195°C~205°C	0.5kg/cm2	30s
Three-acetate fiber fabric	190°C~200°C	0.5kg/cm2	30~40s
Nylon Fabric	195°C~205°C	0.5kg/cm2	30~40s
Acrylic Fabric	200°C~210°C	0.5kg/cm2	30s
Two-acetate Fabric	185°C	0.5kg/cm2	15~20s
Gather propionitrile Fabric	190°C~220°C	0.5kg/cm2	10~15s

Finished Products

Attention

Our Suggestion Before Use Our Offset Transfer Printing Ink

Before use the ink,play a sample plate printing,if the deviation is not great,and then determinethe comp engraving and printing.
Because sublimation ink for gas coloring so can not according to the proportion of ordinary printing Fapai printing.

a. To get 50%C on fabric,the color on paper should be 30%C;

b. To make red PS-plate,the ratio is 100%M and 35%-40%Y;

c. To make blue PS-plate,the ratio is 100%C and 20%M;

d. To make green PS-plate,the ratio is 80%C and 90%Y;

e. To get yellow like Asian skin,the ratio is 10%~11%M and a little cyan.Cyan can be adjusted according to your requirment.

Packaging & Shipping

Packaging

1kg/tin, 2kg/tin, 12kg/carton. carton inside, wooden outside.

Storage Indications

Products in their original unopened containers maintain their characteristics for three year if stored in a well ventilated place with
a temperature between + 5° and + 40°C.Products opened, but immediately closed after use, have a shelf life of at least 12 months.
