cymk sublimation gravure transfer ink
1. Use Principle of Sublimation Rotogravure Ink
It it used on rotogravure machine. With the ink,first print image on paper, then transfer the image onto
various materials by heat transfer press, especially for polyester fabric. Under high temperature, the ink
will become gas and go into fabric.
2. Applicable Paper
Newsprint Paper, coated or calendered paper from 40 - 60 gr/m² with stable dimensions.
3. Printing Materials
All kinds of synthetic fabrics, Mug, Wood, Ceramic, and etc.
4. Suitable Fabrics
Polyester fabric, Triacetate fabric, Nylon fabric, Acrylic fabric, Polypropylene nitrile.
5. Colors
Magenta,Yellow,Cyan,Black.
6. Advantage
(1)Good stability on the machine,clear dot reproduction,excellent ink-water balance.
(2)Be able to adapt to the demand for middle-speed or high-speed printing.
(3)During the normal condition, use the ink on the machine directly.
7. Transfer temparature
About 190~220°C
8. Transfer time
About 20~40 seconds
The following is the transfer printing parameters for your reference
|
Name of fabric |
Transfer temperature |
pressure |
Time |
|
Polyester fabric |
205°C~220°C |
0.5kg/cm2 |
10~30 seconds |
|
Polyester deformation fabric low elastic |
195°C~205°C |
0.5kg/cm2 |
30 seconds |
|
Triacetate fabrics |
190°C~200°C |
0.5kg/cm2 |
30~40 seconds |
|
Nylon fabric |
195°C~205°C |
0.5kg/cm2 |
30~40 seconds |
|
Acrylic fabric |
200°C~210°C |
0.5kg/cm2 |
30 seconds |
|
Two acetate fiber fabric |
185°C |
0.5kg/cm2 |
15~20 seconds |
|
Polypropylene nitrile |
190°C~220°C |
0.5kg/cm2 |
10~15 seconds |
Dye degree:(European Standard)
|
Color fastness |
||||
|
Color |
Magenta(HPA604) |
Yellow(HPA204) |
Blue(HPA404) |
Black(HPA804) |
|
Rank |
5-6 |
6 |
4 |
4 |
Please be noted
The control of the colors is always carried out after the transfer of the final supports.The relationship between
the temperature and the time of contact is important in order to havethe optimal color resistance and ink
penetration (the longer the time of transfer, the better the ink penetration of the fabric).
Packing
10Kg/barrel ,20kg/barrel, 25kg/barrel. carton inside,wooden outside.
